MOUNTING BRACKETS & HARDWARE

Sign Brackets
201 stainless steel sign brackets are available for sign mounting, using Strapbinder stainless
steel coils and banding up to 3/4" wide. The brackets are threaded and available with or
without bolts and washers.
Weight
Item No. Type Description Qty/Box
lbs kg
AACS216455 Bolt Stainless Steel 5/16” - 18 x 3/4” 50 1.5 .7
AAWL213455 Washer Plastic 7/8” OD x 3/8” ID 50 .5 .2
ST000 Straight Leg Bracket Pack Stainless Stee Bracketl with SS Bolts and Plastic Washer 50 7.6 3.4
ST004 Straight Leg Bracket Stainless Steel Bracket only 50 6.0 2.7
ST021 Flared Leg Bracket Pack Stainless Steel Bracket with SS Bolt and Plastic Washer 50 7.6 3.4
ST022 Flared Leg Bracket Stainless Steel Braccket only 50 6.0 2.7

Polebinder Bolt Clamp
Extruded aluminum fittings with zinc plated bolt, nut and washer. To be used with Strapbinder
Band for mounting pole hardware.
Weight
Item No. Description Qty/Box
lbs kg
ST500 Polebinder/bolt clamp for use with ¾" strapbinder band. 50 25 11.3
Includes plated nut, bolt 3/8-16 x 6" and washer
ST504 Polebinder bolt/clamp for use with 1-1/4" (31.7 mm) Bigbinder band. 25 31.5 14.3
Includes plated nut, bolt 5/8-11 x 8" & washer
Special order only. Non-cancellable, non-returnable.

Mounting Plate
Strapping holds this extruded aluminum mounting plates to utility poles. Includes 5/8-11 x 2"
bolt and nut.
Weight
Item No. Description Qty/Box
lbs kg
ST510 Mounting Plate 1-1/2" x 4-3/4" with 2" Plated Bolt 25 15 6.8
ST512 Heavy Duty Mounting Plate 1-1/2" x 5-1/4" with 2" Plated Bolt 25 21.3 9.7

®
Ideal Tridon 56-0 Snaplock Quick Release
Snaplock worm drive clamps are desgined with a swivel-action that locks the screw to the band,
making installation and removal much faster. The 56-0 clamp is constructed with 200 stainless
steel 9/16" band and housing, a carbon steel bridge, and a 5/16" carbon steel screw.
Snaplock is best suited for signs, seasonal banners, and general strapping and bundling.

Item No. Size Min (in) Max (in) Min (mm) Max (mm)
56128 128 1-3/4 8-1/2 45 216
56188 188 2 12-1/4 51 311
For more sizes and information, go to page 22 in the Ideal Tridon catalog.

Identification Tags
The ID tags are .015" thick and can be fastened with Strapbinder Pow'r-Wrap ties (pg 5).
Weight
Item No. Description Material Qty/Box
lbs kg
ST750350 3/4” X 3-1/2” T304 100 .6 .30
ST750200 3/4” X 2” T316 100 .5 .20
ST150250 1-1/2” X 2-1/2” T316 100 1.4 .67
