Page 10 - Strapbinder

TENSIONING TOOLS

Steelbinder™ Tensioner
ST101
This heavy duty windless tensioner is used with stainless steel strapping. It features a cutter
and hammer knob for wing seal closing. For use with 3/8" x 3/4" x .030 (9.3-19.0 x 0.76
mm) maximum strapping. Highly portable, fast, reliable ratchet type tool. For sign hanging,
insulation work and general application.

Pistol Grip Tensioner
ST1902D
Fast, reliable, easy to use for light duty application with 3/8" x 3/4" x .023 (9.3-19.0 x
0.58 mm) maximum strapping. Re-settable rack for additional take-up. One hand pistol grip
operation is ideal for insulation and other light duty applications.
Weight
Item No. Description
lbs kg
ST101 3/8"-3/4" x .030 (9.3-19.0 x 0.76 mm) 3.0 1.4
ST1902D 3/8" x 3/4" x .023 (9.3-19.0 x 0.58 mm) pistol grip 2.5 1.1

Steelbinder™ "job Site" Strapping

Ribbon Wound Coils
For general packaging, bundling and palletizing. Painted black carbon steel Strapbinder
Strapping is made from tempered, shock resistant steel for a wide range of packaging
applications ranging from general palletizing to unitizing small irregular shapes.
Width Thickness Break Strength Weight Qty/Coil
Item No.
inch mm inch mm lbs lbs kg ft M
ST305X 1/2 12.7 .020 .51 800 29.0 13.2 865 264
ST306X 1/2 12.7 .025 .63 1,000 29.0 13.2 690 210
ST308 5/8 15.8 .020 .51 1,000 37.0 16.8 865 264
ST309 5/8 15.8 .025 .63 1,250 37.0 16.8 690 210
ST311 3/4 19.0 .020 .51 1,200 44.0 20.0 865 264
ST312 3/4 19.0 .025 .63 1,500 44.0 20.0 690 210
* Use stainless steel wing seals with Steelbinder Strapping.

Portable Strap Dispenser For Steelbinder™ Strapping
ST400
Heavy duty, lightweight steel strap dispenser features brackets to hold tensioning and cutting
tools along with a covered tray to carry seals. Handle is provided for maximum portability.

Strap size Weight
Item No. Description Coil Type
inches mm lbs kg
ST400 Vertical dispenser Ribbon 3/8-3/4 9.5-19.0 15 6.8

10 | STRAPBINDER PRODUCT CATALOG
